Corsair HX1200i Shift ATX v3.1 PSU Review

The Corsair HXi Shift series will coexist with the HXi line, with the major difference being the side modular panel, thanks to the different platform at the internals, allowing for the “shift” of the modular panel.

The Corsair HX1200i Shift is (or will be) included in my best ATX v3.x & PCIe 5.x PSU picks article.

This is the first time I will use the provided reviewer’s guide extensively, and Corsair explains everything clearly in it, so I see no point in trying to explain the new HXi Shift line entirely on my own—except for one crucial fact that is not highlighted in the reviewer’s guide. The HXi Shift members don’t have a -12V rail, which is a remnant of the past, not offering anything; on the contrary, it affects efficiency. This is a good call!

The first SHIFT PSU with Cybenetics Platinum-certified efficiency.
It’s the first Corsair power supply with a built-in iCUE LINK System Hub. It’s not a passthrough, as the System Hub is internal to the PSU, so iCUE LINK systems don’t need to mount a System Hub inside the case. This helps system builders by eliminating the need for a six-pin PCIe power connector. Although it is internal to the PSU, it is the same System Hub as before, supporting up to 24 devices across two channels.

Differences Between HXi SHIFT and HXi

HXi Shift has side-mounted connectors
HXi Shift has a built-in iCUE LINK System Hub
HXi Shift has a native 12V-2×6 connector/cable, with 2x connectors on HX1500i SHIFT. HXi uses standard Type 4 connectors and Type 4 to 12V-2×6 cables.
HXi Shift has outlines around the connectors to reduce confusion about connector types.
The HX1500i Shift includes dual 12V-2×6 connectors for multi-GPU builds.
HXi Shift uses flexible Type-5 cables, and HXi uses Type-4 cables.

Check out our top ATX v3.1 PSU guide before purchasing your next PSU.

High-Capacity ATX v3.1 PSU Reviews:

Cybenetics PSU Test Database

Best ATX v3.x PSUs

Technical Specifications:

Manufacturer (OEM): CWT
Max Power: 1200W
Cybenetics Efficiency: [115V] Cybenetics Platinum (89.955%), [230V] Cybenetics Platinum (91.557%)
Noise: [115V] Cybenetics A- (14.77 dB[A]), [230V] Cybenetics A- (14.82 dB[A])
Compliance: ATX v3.1, EPS 2.92
Operating Temperature (Continuous Full Load): 0 – 50 °C
Alternative Low Power Mode support: ✓
Power 12V combined: 1200W
Number of 12V rails: 1
Power 5V + 3.3v: 150W
Power 5VSB: 15W
Cooling: 140mm Fluid Dynamic Bearing Fan (NR140HP)
Semi-Passive Operation: ✓
Modular Design: Yes (Fully)
High Power Connectors: 2x EPS (2x cables), 1x 12+2 pin (600W), 4x PCIe 6+2 pin (3x cables)
Peripheral Connectors: 8x SATA (2x cables), 8x 4-pin Molex (2x cables)
ATX Cable Length: 610mm
EPS Cable Length: 650mm
12+2 pin PCIe Cable Length: 650mm
6+2 pin PCIe Cable Length: 600mm
Distance between SATA/4-pin Molex: 100mm
In-cable capacitors: No
Dimensions (W x H x D): 150 mm x 85 mm x 180mm
Weight: 1.99 kg (4.39 lb)
Warranty: 10 Years
MSRP (excluding VAT): $400

Power Specifications

Rail		3.3V	5V	12V	5VSB
Max. Power	Amps	25	25	100	3
Max. Power	Watts	150		1200	15
Total Max. Power (W)		1200
