The PCCooler YT1000 features a Cybenetics Platinum efficiency rating and it is also compliant with the ATX v3.1 spec, meaning that it can deliver double its power for short periods, without issues. Read the review to learn more about this product!
The PCCooler YT1000 is (or will be) included in my best ATX v3.x & PCIe 5.x PSU picks article.
PCCooler is a Chinese brand (by Shenzhen Fluence Technology) known for designing and producing air coolers, liquid coolers, case fans, power supplies, and RGB/ARGB components for PC builds. It emphasizes innovation, holding many patents in heat dissipation and LED lighting technologies, and offers a balance of performance and value. This brand is also publicly listed (stock code 300647 in China).
- PCCooler YT1200 ATX v3.1 PSU Review
- PCCooler YT1000 ATX v3.1 PSU Review
- PCCooler YT850 ATX v3.1 PSU Review
The PCCooler YT line consists of three models with maximum power ratings of 850W, 1000W, and 1200W. All are certified by Cybenetics, and in today’s review, I will evaluate the middle member of the line.
The PCCooler YT1000 is Platinum certified by Cybenetics, and it also meets the ATX v3.1 compliance standard, as approved by the same agency. At the time of the review, I was unable to find any price information on this product.
Check out our top ATX v3.1 PSU guide before purchasing your next PSU.
ATX v3.x 1000W PSU Reviews:
- 1st Player NGDP 1000W PSU Review
- ASUS ROG Thor 1000W Platinum III ATX v3.1 PSU Review
- be quiet! Pure Power 13 M 1000W ATX v3.1 PSU Review
- be quiet! Pure Power 11 FM 1000W PSU Review
- be quiet! Power Zone 2 1000W ATX v3.1 PSU Review
- be quiet! Dark Power 13 1000W PSU Review
- Cougar GEX X2 1000W PSU Review
- Endorfy Supremo FM6 1000W ATX v3.1 PSU Review
- FSP Hydro Ti Pro 1000W PSU Review
- FSP Hydro G Pro 1000W ATX v3.0 PSU Review
- FSP VITA GM 1000W ATX v3.1 PSU Review
- Gamer Storm PQ1000M-V2 ATX v3.1 PSU Review
- Montech Titan Gold 1000W PSU Review
- Micronics Wizmax G 1000W ATX v3.1 PSU Review
- MSI MAG A1000GLS PCIE5 ATX v3.1 PSU Review
- Seasonic Vertex PX-1000 ATX v3.0 PSU Review
- Super Flower Leadex VII Gold 1000W (SF-1000F14XG) PSU Review
- Super Flower Leadex VII PRO 1000W ATX v3.1 PSU Review
- Sharkoon Rebel P20 1000W ATX v3.1 PSU Review
- Thermaltake Toughpower GF3 1000W ATX v3.0 PSU Review
- Vetroo 1000W ATX v3.0 PSU Review
- Manufacturer (OEM): Andyson
- Max Power: 1000W
- Cybenetics Efficiency: [115V] Cybenetics Platinum (89.926%), [230V] Cybenetics Platinum (91.620%)
- Noise: [115V] Cybenetics A- (26.87 dB[A]), [230V] Cybenetics A- (26.93 dB[A])
- Compliance: ATX v3.1, EPS 2.92
- Operating Temperature (Continuous Full Load): 0 – 50 °C
- Alternative Low Power Mode support: ✓
- Power 12V combined: 1000W
- Number of 12V rails: 1
- Power 5V + 3.3v: 100W
- Power 5VSB: 15W
- Cooling: 135mm Fluid Dynamic Bearing Fan (HA13525H12F-Z)
- Semi-Passive Operation: ✓ (Selectable)
- Modular Design: Yes (Fully)
- High Power Connectors: 2x EPS (2x cables), 1x 12+4 pin (600W), 3x PCIe 6+2 pin (3x cables)
- Peripheral Connectors: 9x SATA (3x cables), 3x 4-pin Molex (3x cables)
- ATX Cable Length: 600mm
- EPS Cable Length: 650mm
- 12+4 pin PCIe Cable Length: 650mm
- 6+2 pin PCIe Cable Length: 600mm
- Distance between SATA/4-pin Molex: 150mm
- In-cable capacitors: No
- Dimensions (W x H x D): 150 mm x 85 mm x 150mm
- Weight: 1.75 kg (3.86 lb)
- Warranty: 10 Years
- MSRP (excluding VAT): no info
Power Specifications
| Rail | 3.3V | 5V | 12V | 5VSB | -12V | |
| Max. Power | Amps | 20 | 20 | 83.3 | 3 | 0.3 |
| Watts | 100 | 999.6 | 15 | 3.6 | ||
| Total Max. Power (W) | 1000 | |||||
Average efficiency increased by only 0.3% compared to the YN series. Not impressive.
