Enermax Liqmaxflo 360mm A-RGB AIO Review

The Enermax Liqmaxflo 360mm A-RGB is a high-performance all in one water-cooling solution, featuring ARGB fans and a smaller, ARGB, fan on its block, assisting in the mainboard’s VRMs cooling. You can replace the liquid in the radiator or refill it, for maintantance purposes, and this is a significant advantage over other AIOs where no service can be performed once the time comes.

Enermax is also quite active in power supplies and in the cooling section. I will evaluate the Liqmaxflo, featuring the 360mm radiator in this review. According to Enermax, this cooler features a dual-chamber Extreme pump using the brand’s patented Shunt-Channel technology with an enlarged coolant inlet and optimized flow design, which increases the pump’s pressure by up to 30% and the coolant flow rate by up to 20%. Enermax claims this pressure and flow rate increase can lead to up to 4°C lower temperatures for every 100W load! The testing results will confirm that in both AMD and Intel systems.


Instead of the usual 27mm thick radiator, Enermax opted for a thicker one at 38mm for higher performance. The only problem is that some chassis might not have enough space to install the radiator with its fans. Enermax has the Liqmaxflo SR models, which come with 27mm thick radiators for those of you who need a slimmer radiator. There are some more interesting details about this product, which I will mention later in this review.

Enermax Liqmaxflo Models Amazon.com Price
Liqmaxflo SR 120mm $53
Liqmaxflo SR 240mm $80
Liqmaxflo SR 360mm $100
Liqmaxflo 360mm $128
Liqmaxflo 420mm $150

This table shows the street prices for all Liqmaxflo models but the 240mm one with the thick radiator, for which no price info was available.

Cybenetics Coolers Database


Technical Specifications:
  • Model name: Liqmaxflo 360mm A-RGB AIO (ELC-LMF360T-ARGB)
  • Color: Black
  • Socket Support Intel: LGA 1700/1200/115x/2066/2011/2011-3(Square ILM)/1366
  • Socket Support AMD: AM5/AM4
  • Radiator Dimensions: 317 (L) x 138 (W) x 38 (H) mm
  • TDP: 400W
  • Cold Plate Material: Copper
  • Water Block Dimensions: 70 x 70 mm
  • Radiator Material: Aluminum
  • Radiator Dimensions: 400 x 120 x 38 mm
  • Tube Length: 400mm
  • Pump Speed: 1200~3000 RPM (PWM controlled)
  • Pump Bearing: Ceramic Bearing
  • Pump MTBF: ≧ 50,000 hrs
  • Pump Connector: 4-Pin
  • Pump Rated Voltage: 12 VDC
  • Pump Rated Current: 0.43 A
  • Pump Rated Current – RGB LED: 0.24 A
  • VRM Fan Diameter: 60mm
  • VRM Fan Speed (Max): 3000 RPM
  • VRM Fan Airflow: 18.73 CFM
  • VRM Fan Static Pressure: 2.17 mm-H20
  • Number of Radiator Fans: 3x
  • Fan Models: UCSFARGB12P-LMF
  • Fan MTTF: ≧ 60,000 hrs
  • Bearing Type: No official info
  • Fan Dimensions: 120 x 120 x 26.8 mm
  • Fan ARGB: ✓
  • Fan Daisy Chain: ✓
  • Fan Speed: 500~1800 RPM ±10%
  • Fan Airflow: 58.03 CFM
  • Fan Air Pressure: 2.4 mm-H2O
  • Max Noise Output: 34.3 dB(A)
  • Fan Connector: 8-pin
  • Thermal Grease (pre-applied): Dow Corning® TC-5888
  • Street Price (excl. VAT): $128
  • Warranty: 5 years
Pages ( 1 of 10 ): 1 2345678910Next »
