Box & Bundle
At the face of the box is a photo of the PSU, along with the ATX v3.0 and PCIe 5.0 icons. Shame that FSP didn’t use the Cybenetics certifications that it got for this PSU.
Product Photos
These photos are from the special edition sample with a unique coating.
I also provide photos of the standard model to show the differences from the special edition! The only difference is in the coating of the chassis. The exterior design remains the same.
Cables
| Modular Cables | ||||
| Description | Cable Count | Connector Count (Total) | Gauge | In Cable Capacitors |
|---|---|---|---|---|
| ATX connector 20+4 pin (600mm) | 1 | 1 | 16-22AWG | Yes |
| 4+4 pin EPS12V (700mm) | 2 | 2 | 16AWG | No |
| 6+2 pin PCIe (650mm) | 3 | 3 | 16AWG | No |
| 6+2 pin PCIe (650mm+150mm) | 2 | 4 | 16-18AWG | No |
| 12+4 pin PCIe (700mm) (600W) | 1 | 1 | 16-24AWG | No |
| SATA (500mm+150mm+150mm+150mm) | 2 | 8 | 18AWG | No |
| SATA (500mm+150mm) / 4-pin Molex (+150mm+100mm) | 1 | 2 / 2 | 18AWG | No |
| SATA (500mm+150mm) / 4-pin Molex (+150mm) / FDD (+150mm) | 1 | 2 / 1 / 1 | 18-22AWG | No |
Plenty of cables and connectors, including two EPS, three 6+2 pin PCIe on dedicated cables, and a single 12+4 PCIe connector, set at 600W max power output. Only the ATX connector uses in-cable caps for better ripple filtering, and the number of peripheral connectors is adequate, with SATA and 4-pin Molex cables combined in two cables. The distance between the peripheral connectors is long enough at 150mm, with only one of the 4-pin Molex connectors being 100mm from the other.
