Box & Bundle
When I received this sample, it didn’t come with the retail box, so the only thing I have to show you here is a photo of the provided cables.
Product Photos
This is the typical DeepCool PSU design, with the weird-looking fan grille with large openings allowing for good airflow. The PSU’s dimensions are compact, given its max power, thanks to the 160mm length. At its front size, besides the power switch, you will also find the hybrid mode button for toggling on/off the fan’s semi-passive operation. Given the increased capacity, I expected a heavy-duty IEC 60320 C-20 AC receptacle, not a plain C14 one.
Cables
| Modular Cables | ||||
| Description | Cable Count | Connector Count (Total) | Gauge | In Cable Capacitors |
|---|---|---|---|---|
| ATX connector 20+4 pin (600mm) | 1 | 1 | 16AWG | No |
| 4+4 pin EPS12V (700mm) | 2 | 2 | 16AWG | No |
| 6+2 pin PCIe (650mm) | 5 | 5 | 16AWG | No |
| 2x 8 pin connector to 12+2 pin PCIe (650mm) (600W) | 1 | 1 | 16-24AWG | No |
| 12+4 pin PCIe (650mm) (600W) | 1 | 1 | 16-24AWG | No |
| SATA (500mm+150mm+150mm+150mm) | 2 | 8 | 18AWG | No |
| 4-pin Molex (500mm+150mm+150mm+150mm) | 1 | 4 | 18AWG | No |
Plenty of cables and connectors are provided, including two high-power cables set at 600W each. The first takes power from a pair of 2x 8pin sockets, while the other is through a 12VHPWR header, at least in my sample, which was manufactured in Q2 2023. CWT might have updated the 12+4 pin headers on the newer production batches to 12V-2×6. This will be a silent upgrade, though.
