In today’s review I will look at the MSI MAG A750GLS, which is made by one of the largest Chinese PSU OEMs, Huntkey. Read the full review to learn more about this PSU and how improved is its performane and noise output compared to the A750GL model.
The MSI MAG A750GLS PCIE5 is (or will be) included in my best ATX v3.x & PCIe 5.x PSU picks article.
There is no doubt that the MSI MAG A-GL is a decently performing line, but it’s not suitable for users who want silent operating products. Hence, MSI thought to offer the MAG A-GLS(ilent) line with PSUs featuring much more relaxed fan-speed profiles than the A-GL ones. I have already evaluated the 1000W and 850W models of the line and noticed that indeed, the average noise difference with the plain “GL” model, which uses a different platform, is substantial. In this review, I will evaluate the A750GLS. Briefly, the 1000W and 850W models of the line are made by CWT, while Huntkey makes the two lower-capacity ones.
A side note, all A-GLS units are tested and certified by Cybenetics.
The MAG A750GLS is Platinum certified in the Cybenetics standard, and it also has a Cybenetics A noise rating. Its dimensions are standard for a 750W PSU, measuring 150mm in depth. At the time of the review, I was unaware of the product’s price.
Look at our best ATX v3.1 PSU guide before buying your next PSU.
ATX v3.1 750W PSU Reviews:
- 1st Player NGDP 750W PSU Review
- ASUS TUF Gaming 750W Bronze PSU Review
- be quiet! Power Zone 2 750W ATX v3.1 PSU Review
- Cooler Master GX III 750W ATX v3.0 PSU Review
- DeepCool PN750D ATX v3.1 PSU Review
- Enermax Revolution D.F.12 750W PSU Review
- Montech Titan PLA 750W ATX v3.1 PSU Review
- Sharkoon Rebel P20 750W ATX v3.1 PSU Review
- SilverStone Triton 750Rx ATX v3.1 PSU Review
- Thermaltake Toughpower PF3 750W PSU Review
- Thermaltake Toughpower GF A3 750W PSU Review
- Thermaltake Toughpower GF3 ARGB 750W PSU Review
- Thermaltake Toughpower SFX 750W Gold PSU Review
- Thermaltake Toughpower GF3 750W ATX v3.0 PSU Review
- XPG KYBER 750W ATX v3.1 PSU Review
- XPG Core Reactor II VE 750W PSU Review
- FSP VITA GM 750W ATX v3.1 PSU Review
- Manufacturer (OEM): Huntkey
- Max Power: 750W
- Cybenetics Efficiency: [115V] Cybenetics Platinum (89.664%), [230V] Cybenetics Platinum (91.831%)
- Noise: [115V] Cybenetics A (24.46 dB[A]), [230V] Cybenetics A (24.42 dB[A])
- Compliance: ATX v3.1, EPS 2.92
- Operating Temperature (Continuous Full Load): 0 – 50 °C
- Alternative Low Power Mode support: Yes
- Power 12V combined: 750W
- Number of 12V rails: 1
- Power 5V + 3.3v: 100W
- Power 5VSB: 12.5W
- Cooling: 135mm Fluid Dynamic Bearing Fan (HA13525H12F-Z)
- Semi-Passive Operation: ✓
- Modular Design: Yes (Fully)
- High Power Connectors: 2x EPS (1x cable), 4x PCIe 6+2 pin (3x cables), 1x PCIe 12+4 pin (450W)
- Peripheral Connectors: 5x SATA (2x cables), 2x 4-pin Molex (2x cables), 1x FDD (1x cable)
- ATX Cable Length: 600mm
- EPS Cable Length: 650mm
- 12+4 pin PCIe Cable Length: 600mm
- 6+2 pin PCIe Cable Length: 600mm
- Distance between SATA/4-pin Molex: 150mm
- In-cable capacitors: No
- Dimensions (W x H x D): 150 mm x 85 mm x 150mm
- Weight: 1.35 kg (2.98 lb)
- Warranty: no info
- MSRP (excluding VAT): no info
Power Specifications
| Rail | 3.3V | 5V | 12V | 5VSB | -12V | |
| Max. Power | Amps | 18 | 18 | 62.5 | 2.5 | 0.3 |
| Watts | 100 | 750 | 12.5 | 3.6 | ||
| Total Max. Power (W) | 750 | |||||
