The Lian Li EG1000G is an ATX v3.1 compliant PSU featuring a unique L-shale design. Read the review to find out how it performs!
The Lian Li EG1000G ATX v3.1 is (or will be) included in my best ATX v3.x & PCIe 5.x PSU picks article.
I have already evaluated the Lian Li EG1200G model, so the time has come for the 1000W model to be tested. Like its big brother, it offers a removable USB/fan hub with four USB and six fan headers.
This concept could help users wanting more USB headers and those who don’t want to buy a separate PWM/RGB controller for their fans. Each fan header supports up to 2A, so you won’t have a problem with strong fans.
| EDGE 1200W Black / White | $179.99 |
| EDGE 1000W Black / White | $154.99 |
| EDGE 850W White | $119.99 |
| EDGE 850W Black | $109.99 |
| EDGE 750W Black | $99.99 |
| EDGE Hub White | $16.99 |
| EDGE Hub Black | $16.99 |
The 1200W and 1000W units will come with the EDGE hub, which will be optional in the rest of the family models. This unit is made by Helly, which has a close partnership with Lian Li.
1000W ATX v3.x PSU Reviews:
- 1st Player NGDP 1000W PSU Review
- Asus Rog Strix 1000W Platinum ATX v3.1 PSU Review
- be quiet! Dark Power 13 1000W PSU Review
- be quiet! Pure Power 11 FM 1000W PSU Review
- Corsair TX1000 ATX v3.1 PSU Review
- Cougar GEX X2 1000W PSU Review
- FSP Hydro Ti Pro 1000W PSU Review
- FSP Hydro G Pro 1000W ATX v3.0 PSU Review
- FSP VITA GM 1000W ATX v3.1 PSU Review
- Vetroo 1000W ATX v3.0 PSU Review
- Montech Titan Gold 1000W PSU Review
- Seasonic Vertex PX-1000 ATX v3.0 PSU Review
- Sharkoon Rebel P20 1000W ATX v3.1 PSU Review
- Super Flower Leadex VII Gold 1000W (SF-1000F14XG) PSU Review
- Super Flower Leadex VII PRO 1000W ATX v3.1 PSU Review
- Thermaltake Toughpower GF3 1000W ATX v3.0 PSU Review
- Green Medel GP1000B-EDGE ATX v3.1 PSU Review
- Manufacturer (OEM): Helly
- Max Power: 1000W
- Cybenetics Efficiency: [115V] Cybenetics Platinum (89.305%), [230V] Cybenetics Platinum (91.673%)
- Noise: Cybenetics A+ (15-20 dB[A])
- Compliance: ATX v3.1, EPS 2.92
- Operating Temperature (Continuous Full Load): 0 – 40 °C
- Alternative Low Power Mode support: Yes
- Power 12V combined: 1000W
- Number of 12V rails: 1
- Power 5V + 3.3v: 120W
- Power 5VSB: 15W
- Cooling: 120mm Fluid Dynamic Bearing Fan (HA1225M12F-Z)
- Semi-Passive Operation: ✓
- Modular Design: Yes (Fully)
- High Power Connectors: 2x EPS (2x cables), 5x PCIe 6+2 pin (4x cables), 1x PCIe 12+4 pin (600W)
- Peripheral Connectors: 12x SATA (4x cables), 4x 4-pin Molex (1x cable)
- ATX Cable Length: 625mm
- EPS Cable Length: 745mm
- 12+4 pin PCIe Cable Length: 650mm
- 6+2 pin PCIe Cable Length: 650mm
- Distance between SATA: 150/15mm
- Distance between 4-pin Molex: 150mm
- In-cable capacitors: No
- Dimensions (W x H x D): 150 mm x 85 mm x 180mm
- Weight: 1.70 kg (3.74 lb)
- Warranty: 10-years
- MSRP (excluding VAT): $155
Power Specifications
| Rail | 3.3V | 5V | 12V | 5VSB | -12V | |
| Max. Power | Amps | 20 | 20 | 83 | 3 | 0.3 |
| Watts | 120 | 996 | 15 | 3.6 | ||
| Total Max. Power (W) | 1000 | |||||
